90 Degree Male Elbow Composite PTC Fitting

Part #: DP-243890

Brand: Duraparts

$11.02

Works w/ SAE J844 Nylon Tubing
Meets DOT FMVSS71.106 & SAE J1131, J2494 Standards
-45º to 140º Temperature Range
Saves 75% Assembly Time Over Standard Compression Fittings
Full Flow Design
Ultraviolet & Vibration Resistant
24% to 33% Weight Savings Over Brass
Positive Release Bushing for Ease of Insertion & Removal of Tubing
Thread Sealant Applied to All Male Pipe Threads to Reduce Installation Time
Superior Tube Retention System & Seal Design For Holding & Side Load Retention
Maximum Operating Pressure 150 PSI

Specifications

Outside Diameter

5/8"

Thread Size

1/2" NPT

Cross-Reference Part Numbers

C1869-10S, 12-94108, 12-94108, KV2L15-37S, A-SME90-16, S S-24389, 369PTC108, S-24389, 12-94108, VEL016281, 177.116910D, 16281, KV2L15-37S
